Clearance Lumix BS1H Full-Frame Box-Style Live and Cinema Camera Digital Cinema Cameras
$180.00
Overview The Panasonic Lumix BS1H Full-Frame Box-Style Live and Cinema Camer…
The Panasonic Lumix BS1H Full-Frame Box-Style Live and Cinema Camera is a versatile box-style camera that features the cinema-quality video performance of the LUMIX S1H in an easy-to-deploy profile. The BS1H contains a 24.2MP35mm full-frame CMOS sensor with Dual Native ISO technology that captures 6K resolution at maximum ISO 51200. Maximizing the use of the pixels in the full-frame image sensor, the LUMIX BS1H is capable of 6K/24p, 5.4K/30p (3:2) or 5.9K/30p (16:9) high-resolution, smooth video recording. It also provides 10-bit 60p 4K/C4K HEVC video and 4:2:210-bit 4K30p in H.264 recording modes. The BS1H provides 14+ stops of dynamic range inV-Log which is as wide as those of cinema cameras and V-Log / V-Gamut compatible with popular calorimetry called “VariCam Look.”
The BS1H is capable of 4:2:2 10-bit 4K 60p/50p HDMI output. Adopting a new heat dispersion structure, it achieves unlimited video recording in a variety of recording formats, including 4:3 Anamorphic mode. Moreover, [5.9K] / [4K] / [Anamorphic (4:3) 3.5K] 12-bit RAW video data can be output over HDMI to save Apple ProRes RAW in Atomos Ninja V or save Blackmagic RAW in Blackmagic Video Assist 12G HDR. The BS1H offers an IP streaming function over Ethernet, even allowing 4K 60p (50p) video streaming in H.265.
The BS1H provides a variety of practical ports such asa USB 3.1 Type-C, a 3G-SDI (BNC) and an HDMI Type-A terminal which can be used for simultaneous output. Genlock IN and Timecode functions are also available. Power over Ethernet+ (PoE+) makes it is easy to install both physically and electrically. Control over maximum 12 sets of LUMIX BS1H cameras is available using LUMIX Tether for Multicam. Last but not least, 3.5 audio jack,Wi-Fi, Bluetooth and tethered photo shooting with LUMIX Tether for Multicam software are also available. For even higher quality sound recording, XLR microphone DMW-XLR1 (sold separately) can be used.AnSDK for camera control via USB/LAN will be provided for free.
4096 x 2160p at 23.98/25/29.97 fps (100 to 400 Mb/s)
3840 x 2160p at 23.98/25/29.97 fps (100 to 400 Mb/s)
3328 x 2496p at 23.98/24/25/29.97 fps (150 to 400 Mb/s)
1920 x 1080p at 23.98/29.97/59.94 fps (100 to 200 Mb/s)
1920 x 1080i at 50/59.94 fps (50 to 100 MB/s)
H.265/H.265 Long GOP/MOV 4:2:0 10-Bit:
5952 x 3968p at 23.98/24/25 fps (200 Mb/s)
5376 x 3584p at 25/29.97 fps (200 Mb/s)
5888 x 3312p at 23.98/25/29.97 fps (200 Mb/s)
4096 x 2160p at 23.98/24/29.97/48/50/59.94 fps (200 Mb/s)
H.265/H.265 Long GOP/MOV 4:2:0 10-Bit:
1920 x 1080p at 100/119.88 fps (150 Mb/s)
1920 x 1080p at 47.95/48 fps (100 Mb/s)
80 to 204,800 (Expanded)
5888 x 3312 12-Bit at 23.98/25/29.97 fps
HDMI In Super35 Mode:
4128 x 2176 12-Bit at 23.98/25/29.97/50/59.94 fps
3536 x 2656 12-Bit at 23.98/25/29.97/50 fps
MOV: 24-Bit 96 kHz LPCM Audio
MP4: 24-Bit 48 kHz LPCM Audio
MP4: 24-Bit 96 kHz LPCM Audio
5K (5888 x 3312) in 16:9
5K (5376 x 3584) in 3:2
4K (4096 x 2160) in 17:9
4K (3840 x 2160) in 16:9
1080p (1920 x 1080) in 16:9
1 x HDMI (HDMI 2.0) Output
1 x HDMI (HDMI 2.0) Output
1 x BNC Timecode Data Input/Output
1 x BNC Genlock Data Input/Output
1 x RJ45 LAN Control, Monitor, Video Input/Output
1 x 2.5 mm LANC Control Input
1 x Hot Shoe Mount
- AC Power Adapter
- AC Cable
- Cable Lock Band
- Body Cap
- Hot Shoe Cover
- Audio Terminal Cover
- DC In Terminal Cover
- BNC Terminal Cover
- HDMI Terminal Cover
- Remote Terminal Cover
- Limited 1-Year Warranty
- Limited 3-Year Warranty with Product Registration
