Clearance DR-10X Plug-On Micro Linear PCM Recorder (XLR) Digital Audio Recorders

The DR-10X is compact – fitting in the palm of the hand and lightweight at 56.3 grams. In addition, the mic connector has a locking mechanism that ensures a tight fit to the microphone body giving the entire assembly a solid feel. When recording interviews or reporting that requires high audio quality, a field recorder is normally needed. But for small-scale reporting, you can record high-quality audio with just a microphone and the DR-10X. No need to carry bulky equipment – you can now record with a compact rig that you can hold in one hand. Designed for recording interviews, press conferences, meetings and other professional uses, the recording format used is 48kHz/24-bit mono WAV(BWF format). The recording switch uses a sliding mechanism. This prevents misoperation from accidentally pressing a button. In addition, the hold function can prevent recording from being stopped by accidental contact with a button. Since the DR-10X is designed to be used together with a mic as a single unit, it is engineered to prevent misoperation during recording. Many times, there is only one chance to get the desired audio. This unit has functions to prevent issues related to recording level settings – including a dual recording function that allows you to set the recording level as high as possible while simultaneously recording a backup track at a lower level. In addition, this unit has an automatic gain control function that adjusts the input level to match the input volume. There is also a limiter function. This unit has a built-in clock and supports BWF audio files that can have time information added to them. This feature is helpful for searching and editing recorded audio files. Even though this unit is compact, it can play back recorded files. You can also connect headphones to check recorded data right away and to monitor the input during recording.

Features:

• XLR plug-on connection
• Compatible with dynamic mics as well as battery-powered condenser mics
• 48kHz/24-bit linear PCM mono recording
• WAV files (compatible with BWF format)
• Media: microSD/SDHC cards (supports 32GB capacities)
• Sliding record switch and hold function to prevent misoperation during recording
• Dual recording function
• automatic file closing function to prevent the loss of already recorded data
• XLR connector also can use as external input for external input
• High/Mid/Low recording level settings
• Low-cut filter
• Limiter
• Automatic level function
• With a built-in clock function, supports BWF files that can have time information added, which is convenient for editing and searching
• Time track incrementing function can create new files at regular intervals (every 15 minutes) during recording
• Playback function allows recorded data to be checked immediately
• Headphone output
• Locking mechanism assure a tight connection with the microphone body
• Easy-to-read organic EL display
• micro USB B port enables easy data exchange with computers
• Records at least 10 hours on a single AAA battery by using alkaline batteries (EVOLTA)
• Unit settings can be created and transferred as a computer text file
• Settings can be transferred between multiple DR-10X units using the infrared transmission function
• Firmware can be updated using a microSD card
• RoHS-compliant product
